DCS-7260CX3-64-R
DCS-7260CX3-64-R Arista 7260CX3 switch, 64x 40/100GbE QSFP28
Used, tested & guaranteedIn stock
Condition: Used. Tested & Guaranteed
DCS-7260CX3-64-R, in stock, ships worldwide.
$9,995
A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.
- Model
- DCS-7260CX3-64-R
- Network Ports
- 64 × 40/100GbE
- Connectors
- QSFP28, SFP+
- Type
- Switch
- Condition
- Used, tested & guaranteed
Questions and answers
- What ports does the DCS-7260CX3-64-R have?
- It has 64 × 40/100GbE. Connectors: QSFP28, SFP+.
- What is the throughput of the DCS-7260CX3-64-R?
- Throughput is 12.8 Tbps full duplex (6.4 Tbps) / 4.2 Bpps, 450 ns latency, 42 MB dynamic packet buffer.
- Which way does the air flow on the DCS-7260CX3-64-R?
- Airflow is rear-to-front: intake at the power-supply/fan side, exhaust at the port side (blue PSU and fan handles).
- What power does the DCS-7260CX3-64-R use?
- It uses 2x PWR-745AC-R 745W AC, 1+1 redundant hot-swap, included; switch draws 314W typical / 616W max.
- How much power does the DCS-7260CX3-64-R draw?
- Power draw: typical 314 W (measured at 25C ambient with 50% load and DAC cables); maximum 616 W (measured at 40C with 100% load and maximum power optical transceivers).
- What are the size and weight of the DCS-7260CX3-64-R?
- Dimensions: 19 x 3.5 x 18 inches (48.3 x 8.8 x45.7 cm), W x H x D. Weight: 34lbs (15.6kg).
The Arista DCS-7260CX3-64-R is a switch from the Arista 7260CX3 family with 64 ports of 40/100GbE QSFP28. A separate 2x 1/10GbE SFP+ port is for management. It is a Layer 3 managed platform that runs Arista EOS. This unit is used: inspected, powered on and functionally tested by our technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
DCS-7260CX3-64-R 64x 100GB QSFP28 2x 10GB SFP+ B-F Airflow Switch
TECHNICAL DETAILS
Brand: Arista Family: 7260CX3 Management ports: 2x 1/10GbE SFP+ Layer: Layer 3 (managed) Operating system: Arista EOS Rack units: 2U Airflow: Rear-to-front: intake at the power-supply/fan side, exhaust at the port side (blue PSU and fan handles) Power input: 2x PWR-745AC-R 745W AC, 1+1 redundant hot-swap, included; switch draws 314W typical / 616W max Throughput: 12.8 Tbps full duplex (6.4 Tbps) / 4.2 Bpps, 450 ns latency, 42 MB dynamic packet buffer Dimensions: 19 x 3.5 x 18 inches (48.3 x 8.8 x45.7 cm), W x H x D Weight: 34lbs (15.6kg) Fans: 4 (N+1 redundant), hot-swappable; fan tray FAN-7002-F/R Power supplies: 2 (1+1 redundant), hot-swap; PWR-745AC-F/R or PWR-1900-DC-F/R Power draw (typical): 314 W (measured at 25C ambient with 50% load and DAC cables) Power draw (maximum): 616 W (measured at 40C with 100% load and maximum power optical transceivers) Operating temperature: 0 to 40˚C (32 to 104˚F) Storage temperature: -40 to 70˚C (-40 to 158˚F) Operating altitude: 0 to 10,000 ft, (0-3,000m) CPU: Dual-Core x86 Memory (DRAM): 8 Gigabytes (System Memory) Flash storage: 30 Gigabytes MAC addresses: 264K MAC entries IPv4 routes: 180K IPv4 Routes; 200K IPv4 Host Routes Jumbo frames: 9216 Bytes Packet buffer: 42 MB (Dynamic Buffer Allocation) Latency: 450 ns Console port: 1 x RS-232 serial (RJ-45) USB port: 1 Warranty: 3 years, Townsend Networks Returns: 30 days
WHAT'S INCLUDED
One (1) Arista DCS-7260CX3-64-R. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
Condition: Used, Tested & Guaranteed DCS-7260CX3-64-R was tested by our technicians before listing. How we test is on /testing-process.
WARRANTY & RETURNS
DCS-7260CX3-64-R has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on /warranty and /legal/refunds.
