What ports does the DCS-7050TX3-48C8-F have?

The DCS-7050TX3-48C8-F has 48 × 1/2.5/5/10GbE, with uplinks of 8x 100GbE QSFP28 and 56 data ports in all.

What is the throughput of the DCS-7050TX3-48C8-F?

The DCS-7050TX3-48C8-F has a throughput of 2.56 Tbps, 1 Bpps.

Which way does the air flow on the DCS-7050TX3-48C8-F?

The airflow of the DCS-7050TX3-48C8-F is front to rear.

What power does the DCS-7050TX3-48C8-F use?

The DCS-7050TX3-48C8-F uses AC.

How much power does the DCS-7050TX3-48C8-F draw?

The typical power draw of the DCS-7050TX3-48C8-F is 212W, and its maximum is 346W.

What are the size and weight of the DCS-7050TX3-48C8-F?

The DCS-7050TX3-48C8-F measures 17.3 x 1.75 x 18.4 in (44 x 4.4 x 46.8 cm), W x H x D and weighs 20.6lbs (9.36kgs).

DCS-7050TX3-48C8-F Arista Switch, Front-to-Back, 48x 1/2.5/5/10GbE RJ45 and 8x 100GbE QSFP28

Condition: Refurbished, tested & guaranteed
WARRANTY & RETURNS: DCS-7050TX3-48C8-F has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
Availability: In stock

$13,800

A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.

The Arista DCS-7050TX3-48C8-F is a switch from the Arista 7050TX3 family with 48 ports of 1/2.5/5/10GbE RJ45, 8 ports of 100GbE QSFP28, front-to-back airflow and AC power. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.

Model: DCS-7050TX3-48C8-F
Network Ports: 48 × 1/2.5/5/10GbE
Connectors: RJ45, QSFP28
Type: Switch
Condition: Refurbished, tested & guaranteed

Technical details

Brand	Arista
Family	7050TX3
Uplinks	8x 100GbE QSFP28
Total ports	56
Fastest port	100GbE
Management ports	1
Rack units	1RU
Airflow	Front to rear
Power input	AC
Throughput	2.56 Tbps, 1 Bpps
Dimensions	17.3 x 1.75 x 18.4 in (44 x 4.4 x 46.8 cm), W x H x D
Weight	20.6lbs (9.36kgs)
Fans	2 (1+1 redundant)
Power supplies	2 (1+1 redundant)
Power draw (typical)	212W
Power draw (maximum)	346W
Operating temperature	0 to 40˚C (32 to 104˚F)
Storage temperature	-40 to 70˚C (-40 to 158˚F)
Operating humidity	5 to 90% (listed as Relative Humidity)
Operating altitude	0 to 10,000 ft, (0-3,000m)
CPU	Quad-Core x86
Memory (DRAM)	8 GB
Flash storage	8 GB
MAC addresses	288K MAC entries
IPv4 routes	360K IPv4 Routes
VLANs	4096 VLANs
Jumbo frames	9216 Bytes
Packet buffer	32 MB (Dynamic Buffer Allocation)
Latency	3 usec
Console port	1 (RJ-45)
USB port	1
Certifications	BSMI (Taiwan); FCC Class A (United States); ICES-003 (Canada); CE (European Union)

Arista datasheet

Testing process

Questions and answers

What ports does the DCS-7050TX3-48C8-F have?: The DCS-7050TX3-48C8-F has 48 × 1/2.5/5/10GbE, with uplinks of 8x 100GbE QSFP28 and 56 data ports in all.
What is the throughput of the DCS-7050TX3-48C8-F?: The DCS-7050TX3-48C8-F has a throughput of 2.56 Tbps, 1 Bpps.
Which way does the air flow on the DCS-7050TX3-48C8-F?: The airflow of the DCS-7050TX3-48C8-F is front to rear.
What power does the DCS-7050TX3-48C8-F use?: The DCS-7050TX3-48C8-F uses AC.
How much power does the DCS-7050TX3-48C8-F draw?: The typical power draw of the DCS-7050TX3-48C8-F is 212W, and its maximum is 346W.
What are the size and weight of the DCS-7050TX3-48C8-F?: The DCS-7050TX3-48C8-F measures 17.3 x 1.75 x 18.4 in (44 x 4.4 x 46.8 cm), W x H x D and weighs 20.6lbs (9.36kgs).

7050X3, 48x10GBaseT & 8x100GbE QSFP100, F-R, 2x AC

WHAT'S INCLUDED

One (1) Arista DCS-7050TX3-48C8-F. Includes a rack-mount kit and the power cable(s) to match the switch.

CONDITION & TESTING

Condition: Refurbished, Tested & Guaranteed DCS-7050TX3-48C8-F was tested by Townsend Networks technicians before listing. The test process is on the testing process.
