EX4600-40F-DC-AFI Juniper Switch, Back-to-Front, Used, 24x 1/10GbE SFP+ and 4x 40GbE QSFP+

EX4600-40F-DC-AFI Juniper Switch, Back-to-Front, Used, 24x 1/10GbE SFP+ and 4x 40GbE QSFP+

Condition
Used, tested & guaranteed
WARRANTY & RETURNS
EX4600-40F-DC-AFI has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
Availability
In stock

$2,200

Free US ground shipping
Request a quote415-626-4231

A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.

The Juniper EX4600-40F-DC-AFI is a switch from the Juniper EX4600 family with 24 ports of 1/10GbE SFP+, 4 ports of 40GbE QSFP+, back-to-front airflow and DC power. It runs Junos OS. This unit is used: inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.

Other versions

  • EX4600-40F-AFI

    Refurbished, tested & guaranteedAirflow: Back-to-front (AFI)In stock

    $1,395
  • EX4600-40F-AFO

    Refurbished, tested & guaranteedAirflow: Front-to-back (AFO)In stock

    $545
  • EX4600-40F-DC-AFO

    Used, tested & guaranteedAirflow: Front-to-back (AFO)In stock

    $1,740
Compatible with
Blue, Air In parts only: QFX5100-FAN-AFI fan modules with the AIR IN label, and DC power supplies of the same airflow. Juniper says not to mix modules of different airflow, that blue and orange modules may not be mixed, and that AC and DC supplies may not share the chassis. It places the switch with its AIR IN labels next to the cold aisle.
HOW IT DIFFERS
EX4600-40F-DC-AFI is the DC powered EX4600 with Air In (FRU-to-port) airflow: 24 SFP+ and 4 QSFP+ ports and 2 expansion module slots, in Juniper's hardware guide. Its fan modules are QFX5100-FAN-AFI, labeled AIR IN and colored blue, and its DC power supply is a 650 W unit with dual feeds for power resiliency, the same supply Juniper uses in its QFX5100 switches. Its sister EX4600-40F-DC-AFO has the same ports with Air Out (port-to-FRU) airflow and orange fan modules; EX4600-40F-AFI is the AC version of this airflow.
Model
EX4600-40F-DC-AFI
Network Ports
24 × 1/10GbE
Connectors
SFP+, QSFP+
Type
Switch
Condition
Used, tested & guaranteed

Technical details

BrandJuniper
FamilyEX4600
Uplinks4x 40GbE QSFP+
Total ports28
Fastest port40GbE
Management ports2: 1 RJ-45 and 1 SFP
Operating systemJunos OS
Rack units1 U
AirflowBack-to-front (AFI)
Power inputDC
Dimensions1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm)
Weight21.7 lb (9.84 kg) with PSUs and fans installed
Mountingtwo- and four-post rack mounting options
FansRedundant (N+1), hot-pluggable fan modules
Power supplies2 DC power supplies; dual redundant (1+1), hot-pluggable
Input voltage-36 to -72 V DC power
Operating temperature32° to 104° F (0° to 40° C)
Storage temperature-40° to 158° F (-40° to 70° C)
Operating humidity5% to 90% (noncondensing)
MTBF150,000 hours (predicted)
Switching capacity720 Gbps (unidirectional)/1.44 Tbps (bidirectional)
Forwarding rate1,071 Mpps (wire speed), Layer 2/Layer 3, 64 byte packets
MAC addresses288,000 per system
IPv4 routes128,000 prefixes; 208,000 host routes (unicast)
IPv6 routes64,000 prefixes (unicast)
VLANs4,091 VLAN IDs
Jumbo frames9,216 bytes
Packet buffer12 MB shared buffers
StackingVirtual Chassis, up to 10 interconnected switches
CertificationsCAN/CSA-C22.2 No. 60950-1; UL 60950-1; EN 60950-1; IEC 60950-1; GR-63-Core; GR-1089-Core

Juniper datasheet

Testing process

End of sale and support

ModelAnnouncedEnd of saleEnd of supportNotice
Juniper EX4600Juniper notice

Juniper end-of-life notice TSB109286. End of engineering is 2029-12-29.

Questions about the Juniper EX4600 family

What ports does the EX4600-40F-DC-AFI have?
The EX4600-40F-DC-AFI has 24 × 1/10GbE, with uplinks of 4x 40GbE QSFP+ and 28 data ports in all.
Which way does the air flow on the EX4600-40F-DC-AFI?
The airflow of the EX4600-40F-DC-AFI is back-to-front (AFI).
What power does the EX4600-40F-DC-AFI use?
The EX4600-40F-DC-AFI uses DC.
What are the size and weight of the EX4600-40F-DC-AFI?
The EX4600-40F-DC-AFI measures 1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm) and weighs 21.7 lb (9.84 kg) with PSUs and fans installed.
How much rack space does the EX4600-40F-DC-AFI take?
The EX4600-40F-DC-AFI takes 1 U of rack space.
What temperature range does the EX4600-40F-DC-AFI run in?
The operating temperature range of the EX4600-40F-DC-AFI is 32° to 104° F (0° to 40° C).
Is the Juniper EX4600 end of life?
Yes. Juniper's notice TSB109286, announced 29 June 2026, covers the EX4600-40F-AFI, -AFO, -DC-AFI and -DC-AFO and the EX4600-EM-8F module. Juniper lists the last order date as 29 December 2026, end of engineering as 29 December 2029, the last software version as Junos 21.4 and end of support as 29 December 2031.
What is the difference between AFO and AFI on an EX4600?
Airflow direction. Air Out (AFO) moves air from the port side to the power supply and fan side; Air In (AFI) moves it the other way. Juniper says not to mix AC and DC power supplies, or AFI and AFO power supplies and fan modules, in the same chassis.
Can the EX4600 be stacked with the EX4300?
Yes. Up to 10 switches form an EX4600 Virtual Chassis in a ring. In a mixed Virtual Chassis of EX4600 and EX4300 switches, the EX4600 can be primary, backup or line card while the EX4300 must be a line card; Juniper fully supports the EX4600 as primary from Junos 14.1X53-D25.
What condition and warranty come with a Juniper EX4600 switch from Townsend?
Each listing prints its own condition. Units sold as new, refurbished or used are bench tested before they are listed: every port and module slot is checked and the previous owner's configuration is erased. They are covered by the Townsend warranty from the date of delivery; if the hardware fails in normal use we repair it or replace it with a tested unit, and the length and terms are on our warranty page. Unused hardware can be returned within 30 days of delivery. Juniper software licences and support contracts are not part of our warranty.

Juniper EX4600-40F-DC-AFI / EX4600 Series Switch, 24x 1/10GbE SFP+ + 4x 40GbE QSFP+ Fixed Ports, 2x Expansion Slots, DC Power, Back-to-Front Airflow

WHAT'S INCLUDED

One (1) Juniper EX4600-40F-DC-AFI. Includes a rack-mount kit and the power cable(s) to match the switch.

CONDITION & TESTING

Condition: Used, Tested & Guaranteed EX4600-40F-DC-AFI was tested by Townsend Networks technicians before listing. The test process is on the testing process.
