QFX5110-48S-AFO Juniper Switch, Front-to-Back, Refurbished, 48x 1/10GbE SFP+ and 4x 40/100GbE QSFP28
- Condition
- Refurbished, tested & guaranteed
- WARRANTY & RETURNS
- QFX5110-48S-AFO has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
- Availability
- In stock
$3,465
Free US ground shippingA firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.
The Juniper QFX5110-48S-AFO is a switch from the Juniper QFX5110 family with 48 ports of 1/10GbE SFP+, 4 ports of 40/100GbE QSFP28, front-to-back airflow and AC power. It is a Layer 3 managed platform that runs Junos OS. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
Other versions
- QFX5110-48S-AFI$2,570
Refurbished, tested & guaranteedAirflow: Back-to-front (AFI)In stock
- Compatible with
- Air Out parts only: JPSU-650W-AC-AFO power supplies, with a gold handle or the label AFO, and QFX5110-48S-FANAFO fan modules with the AIR OUT label. Juniper warns against power supplies with different airflow directions in one chassis, and the system raises an alarm if they are mixed.
- HOW IT DIFFERS
- QFX5110-48S-AFO is the front-to-back airflow QFX5110 with 48 SFP+ ports and 4 QSFP28 ports on AC power: the hardware guide lists it as Air Out (ports to FRUs). Air comes in through the vents around the ports and leaves through the fans and power supplies. It uses JPSU-650W-AC-AFO supplies, marked by the label AFO or a gold-colored handle, and QFX5110-48S-FANAFO fan modules, labeled AIR OUT in Juniper Gold. The typical and maximum power consumption Juniper gives the QFX5110-48S, 167 W and 226 W, are the same as for QFX5110-48S-AFI, its Air In sister.
- Model
- QFX5110-48S-AFO
- Network Ports
- 48 × 1/10GbE
- Connectors
- SFP+, QSFP28
- Type
- Switch
- Condition
- Refurbished, tested & guaranteed
Technical details
| Brand | Juniper |
|---|---|
| Family | QFX5110 |
| Uplinks | 4x 40/100GbE QSFP28 |
| Total ports | 52 |
| Fastest port | 100GbE |
| Management ports | 2 management ports: 2x SFP fiber ports or 1x RJ-45 and 1x copper SFP ports |
| Layer | Layer 3 (managed) |
| Operating system | Junos OS |
| Rack units | 1 U |
| Airflow | Front-to-back (AFO) |
| Power input | AC |
| Throughput | 1.76 Tbps / 1.32 Bpps aggregate |
| Dimensions | 1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm); maker header reads W x H x D |
| Weight | 23 lb (10.43 kg) |
| Fans | Redundant (N+1) and hot-pluggable fan modules |
| Power supplies | Dual redundant (1+1) and hot-pluggable; AC |
| Input voltage | 110-240 V single phase AC power |
| Power draw (typical) | 167 W AC |
| Power draw (maximum) | 226 W AC |
| Operating temperature | 32° to 104° F (0° to 40° C) |
| Storage temperature | -40° to 158° F (-40° to 70° C) |
| Operating humidity | Operating: 5% to 90% (noncondensing) |
| Operating altitude | Up to 2,000 ft (610 m) |
| CPU | 1.8 GHz quad-core Intel CPU |
| Memory (DRAM) | 16 GB of memory |
| Flash storage | 64 GB SSD storage |
| MAC addresses | 288,000 per system |
| IPv4 routes | 128,000 prefixes; 208,000 host routes; 64 ECMP paths (unicast) |
| IPv6 routes | 84,000 (unicast) |
| VLANs | 4,093 VLAN IDs |
| Jumbo frames | 9,216 bytes |
| Packet buffer | 16 MB |
| Console port | 1 RS-232 console port |
| USB port | 1 USB 2.0 port |
End of sale and support
| Model | Announced | End of sale | End of support | Notice |
|---|---|---|---|---|
| Juniper QFX5110-48S (AFI, AFO) | Juniper notice |
Juniper TSB17951 (SKU transformation for the QFX5110 and QFX5120). End of engineering is 2031-06-22.
Questions and answers
- Is the Juniper QFX5110-48S end of life?
- Juniper ended the sale of the Juniper QFX5110-48S (AFI, AFO) on October 4, 2021. Its support ends on July 15, 2032. The dates are from the maker notice linked in the end of sale table on this page. The hardware keeps working after them; what ends is the maker's side: new software fixes, support cases and replacement under a maker contract.
Juniper QFX5110-48S-AFO / 48-Port 10GbE SFP+ Switch, 4x QSFP28 40/100GbE Uplinks, Front-to-Back Airflow (Port-Side Intake), Layer 3
WHAT'S INCLUDED
One (1) Juniper QFX5110-48S-AFO. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
Condition: Refurbished, Tested & Guaranteed QFX5110-48S-AFO was tested by Townsend Networks technicians before listing. The test process is on the testing process.
