QFX5110-48S-AFI Juniper Switch, Back-to-Front, Refurbished, 48x 1/10GbE SFP+ and 4x 40/100GbE QSFP28

QFX5110-48S-AFI Juniper Switch, Back-to-Front, Refurbished, 48x 1/10GbE SFP+ and 4x 40/100GbE QSFP28

Condition
Refurbished, tested & guaranteed
WARRANTY & RETURNS
QFX5110-48S-AFI has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
Availability
In stock

$2,570

Free US ground shipping
Request a quote415-626-4231

A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.

The Juniper QFX5110-48S-AFI is a switch from the Juniper QFX5110 family with 48 ports of 1/10GbE SFP+, 4 ports of 40/100GbE QSFP28, back-to-front airflow and AC power. It is a Layer 3 managed platform that runs Junos OS. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.

Other versions

  • QFX5110-48S-AFO

    Refurbished, tested & guaranteedAirflow: Front-to-back (AFO)In stock

    $3,465
Compatible with
Air In parts only: JPSU-650W-AC-AFI power supplies and QFX5110-48S-FANAFI fan modules. If the fan modules have AIR IN labels the power supplies must have AIR IN labels too, so an Air Out supply or fan does not belong in this chassis; to convert it, Juniper says to change out all the fans and power supplies at one time.
HOW IT DIFFERS
QFX5110-48S-AFI is the back-to-front airflow QFX5110 with 48 SFP+ ports and 4 QSFP28 ports on AC power: Juniper's hardware guide lists it as Air In (FRUs to ports). Its power supplies are JPSU-650W-AC-AFI, marked by the label AFI or a blue handle, and its fan modules are QFX5110-48S-FANAFI, labeled AIR IN in Juniper Azure Blue. Juniper gives the QFX5110-48S 167 W of typical and 226 W of maximum power consumption on an input of 90 VAC to 264 VAC. Its sister QFX5110-48S-AFO is the Air Out version, with gold parts.
Model
QFX5110-48S-AFI
Network Ports
48 × 1/10GbE
Connectors
SFP+, QSFP28
Type
Switch
Condition
Refurbished, tested & guaranteed

Technical details

BrandJuniper
FamilyQFX5110
Uplinks4x 40/100GbE QSFP28
Total ports52
Fastest port100GbE
Management ports2 management ports: 2x SFP fiber ports or 1x RJ-45 and 1x copper SFP ports
LayerLayer 3 (managed)
Operating systemJunos OS
Rack units1 U
AirflowBack-to-front (AFI)
Power inputAC
Throughput1.76 Tbps / 1.32 Bpps aggregate
Dimensions1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm); maker header reads W x H x D
Weight23 lb (10.43 kg)
FansRedundant (N+1) and hot-pluggable fan modules
Power suppliesDual redundant (1+1) and hot-pluggable; AC
Input voltage110-240 V single phase AC power
Power draw (typical)167 W AC
Power draw (maximum)226 W AC
Operating temperature32° to 104° F (0° to 40° C)
Storage temperature-40° to 158° F (-40° to 70° C)
Operating humidityOperating: 5% to 90% (noncondensing)
Operating altitudeUp to 2,000 ft (610 m)
CPU1.8 GHz quad-core Intel CPU
Memory (DRAM)16 GB of memory
Flash storage64 GB SSD storage
MAC addresses288,000 per system
IPv4 routes128,000 prefixes; 208,000 host routes; 64 ECMP paths (unicast)
IPv6 routes84,000 (unicast)
VLANs4,093 VLAN IDs
Jumbo frames9,216 bytes
Packet buffer16 MB
Console port1 RS-232 console port
USB port1 USB 2.0 port

Juniper datasheet

Testing process

End of sale and support

ModelAnnouncedEnd of saleEnd of supportNotice
Juniper QFX5110-48S (AFI, AFO)Juniper notice

Juniper TSB17951 (SKU transformation for the QFX5110 and QFX5120). End of engineering is 2031-06-22.

Questions and answers

Is the Juniper QFX5110-48S end of life?
Juniper ended the sale of the Juniper QFX5110-48S (AFI, AFO) on October 4, 2021. Its support ends on July 15, 2032. The dates are from the maker notice linked in the end of sale table on this page. The hardware keeps working after them; what ends is the maker's side: new software fixes, support cases and replacement under a maker contract.

How it differs from the QFX5110-48S-AFO

Here is how Juniper's documents set the QFX5110-48S-AFI apart from the QFX5110-48S-AFO. Airflow: back-to-front on the QFX5110-48S-AFI, against front-to-back on the QFX5110-48S-AFO. Compatible parts for the QFX5110-48S-AFI: Air In parts only: JPSU-650W-AC-AFI power supplies and QFX5110-48S-FANAFI fan modules. If the fan modules have AIR IN labels the power supplies must have AIR IN labels too, so an Air Out supply or fan does not belong in this chassis; to convert it, Juniper says to change out all the fans and power supplies at one time. For the QFX5110-48S-AFO: Air Out parts only: JPSU-650W-AC-AFO power supplies, with a gold handle or the label AFO, and QFX5110-48S-FANAFO fan modules with the AIR OUT label. Juniper warns against power supplies with different airflow directions in one chassis, and the system raises an alarm if they are mixed.

Both are listed with the same rack units: 1 U. Both are listed with the same weight: 23 lb (10.43 kg). Both are listed with the same dimensions (height x width x depth): 1.72 x17.36 x 20.48 in (4.37 x 44.09 x 52.02 cm); maker header reads W x H x D.

Sister listing: QFX5110-48S-AFO

Maker documents: QFX5110 Ethernet Switch Datasheets | HPE Juniper Networking UK&I, Juniper QFX5110 Hardware Guide

Juniper 48 SFP+ AND 4 QSFP28. BACK TO FRONT AC

WHAT'S INCLUDED

One (1) Juniper QFX5110-48S-AFI. Includes a rack-mount kit and the power cable(s) to match the switch.

CONDITION & TESTING

Condition: Refurbished, Tested & Guaranteed QFX5110-48S-AFI was tested by Townsend Networks technicians before listing. The test process is on the testing process.
