BR-VDX6740T-24-F
BR-VDX6740T-24-F Brocade Switch, Front-to-Back, Refurbished, 24x 1/10GbE RJ45
Refurbished, tested & guaranteedEn existencia
Condition: Refurbished, Tested & Guaranteed
BR-VDX6740T-24-F, in stock, ships worldwide.
$745
¿Prefiere orden de compra o transferencia bancaria? También las aceptamos. Solo pídalo.
- Model
- BR-VDX6740T-24-F
- Network Ports
- 24 × 1/10GbE
- Connectors
- RJ45
- Type
- Switch
- Condition
- Refurbished, tested & guaranteed
Probado en nuestras instalaciones por técnicos certificados antes de enviarse. Términos de la garantía
The Brocade BR-VDX6740T-24-F is a switch with 24 ports of 1/10GbE RJ45, front-to-back airflow and AC power. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
HOW IT DIFFERS
BR-VDX6740T-24-F is the copper VDX 6740T at its 24-port base tier, with front-to-rear airflow. Extreme says base models support 24 ports, that its Base-T ports run at 100 Mbps, 1 Gbps or 10 Gbps, and that upgrade licenses go to 48. It has two 500 W AC supplies and five separate fan units, is 10.82 kg and 53.65 cm deep. Its sister BR-VDX6740T-24-R is the rear-to-front version.
TECHNICAL DETAILS
Brand: Brocade Product line: Brocade VDX 6740T Maker description: Brocade VDX 6740T, 24P 10GBASE-T ports only, no optics, AC, non-port-side exhaust airflow Rack units: 1U Airflow: Front-to-back Power input: AC Throughput: 1.28 Tbps switching bandwidth (full duplex), 960 Mpps (chassis rating) Dimensions: 1.68 x 17.22 x 21.12 in (4.27 x 43.74 x 53.65 cm) Weight: 10.82 kg (23.85 lb) with power supplies and fans, no transceivers Fans: 5 cooling fans Power supplies: Two internal, redundant, field-replaceable, load-sharing AC or DC supplies Operating temperature: 0°C to 40°C (32°F to 104°F) Operating humidity: 10% to 85% at 40°C (104°F), noncondensing Operating altitude: 0 to 3048 m (10,000 ft) Acoustic noise: 46.7 dB CPU: 1.5 GHz PowerPC Latency: 3 µs port to port
MAKER'S DOCUMENT
https://web.archive.org/web/20160329041859/http://www.brocade.com/content/dam/common/documents/content-types/datasheet/brocade-vdx-6740-switches-ds.pdf
WHAT'S INCLUDED
One (1) Brocade BR-VDX6740T-24-F. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
Condition: Refurbished, Tested & Guaranteed BR-VDX6740T-24-F was tested by Townsend Networks technicians before listing. The test process is on /testing-process.
WARRANTY & RETURNS
BR-VDX6740T-24-F has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on /warranty and /legal/refunds.
