EX4300-48MP
EX4300-48MP Juniper Switch, Front-to-Back, 48x 1GbE PoE++ RJ45 (24 × 10GbE) and 4x 40GbE QSFP+
Refurbished, tested & guaranteedEn existencia
Condition: Refurbished, Tested & Guaranteed
EX4300-48MP, in stock, ships worldwide.
$2,465
¿Prefiere orden de compra o transferencia bancaria? También las aceptamos. Solo pídalo.
- Model
- EX4300-48MP
- Network Ports
- 48 × 1GbE (24 × 10GbE)
- Connectors
- RJ45, QSFP+
- Type
- Switch
- Condition
- Refurbished, tested & guaranteed
Probado en nuestras instalaciones por técnicos certificados antes de enviarse. Términos de la garantía
The Juniper EX4300-48MP is a switch from the Juniper EX4300 family with 48 ports of 1GbE PoE++ RJ45 (24 × 10GbE), 4 ports of 40GbE QSFP+, front-to-back airflow and AC power. It runs Junos OS. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
Juniper EX4300-48MP / EX4300 multigigabit switch, 24x 1GbE RJ-45 (10/100/1000BASE-T) + 24x multigig RJ-45 (100M/1G/2.5G/5G/10GBASE-T) access ports, 802.3bt PoE++ up to 95W/port (1100W PoE budget), 4x 40GbE QSFP+ dedicated Virtual Chassis ports, 1400W AC power supply, front-to-back airflow
HOW IT DIFFERS
EX4300-48MP is the multigigabit model: 24 ports at 10/100/1000BASE-T and 24 ports at 100/1000/2500/5000/10000BASE-T, with 95 W PoE and a 1400 W AC power supply that provides up to 1100 W of PoE++ power. Its sister EX4300-24P has 24 ports at 10/100/1000BASE-T with PoE-plus on a 715 W supply that provides 565 W, so the 48MP carries more multigigabit ports and a larger PoE budget.
TECHNICAL DETAILS
Brand: Juniper Family: EX4300 Uplinks: 4x 40GbE QSFP+ Total ports: 52 Fastest port: 40GbE Management ports: Dedicated rear panel RJ-45 port for out-of-band management PoE: Yes PoE standard: 802.3bt PoE++ (up to 95W/port) PoE budget: 1100 W Operating system: Junos OS Rack units: 1 U Airflow: Front-to-back Power input: AC Dimensions: Base unit 17.36 x 1.72 x 18.39 in (44.1 x 4.37 x 46.7 cm), W x H x D Weight: 13 lb (5.9 kg) no PSU/fans; 16.1 lb (7.3 kg) with one PSU and two fan modules Fans: Field-replaceable fans: 2 Power supplies: 1400 W AC AFO (715/1100/1400 W AFO options); dual load-sharing hot-swappable Input voltage: 100-120 V/200-240 V Operating temperature: AFO models: 32° to 113° F (0° to 45° C) Storage temperature: -40° to 158° F (-40° to 70° C) Operating humidity: 10% to 85% (noncondensing) Operating altitude: up to 10,000 ft (3,049 m) Acoustic noise: 53.7 dBA CPU: 2.2 GHz Dual-Core Intel Broadwell CPU Memory (DRAM): 8 GB with ECC Flash storage: 50 GB (Storage) Forwarding rate: 714 Mpps MAC addresses: 64,000 per system IPv4 routes: Unicast in hardware: 16,000 prefixes; 32,000 host routes IPv6 routes: Unicast in hardware: 4000 prefixes; 15,000 host routes VLANs: 4093 Jumbo frames: 9216 Bytes Stacking: Virtual Chassis: up to 10 units, 320 Gbps interconnect Console port: Front panel USB console port and rear panel RJ-45 console port USB port: Rear panel USB port (upload Junos OS and configuration files)
MAKER'S DOCUMENT
https://www.juniper.net/content/dam/www/assets/datasheets/us/en/switches/ex4300-line-of-ethernet-switches-datasheet.pdf
WHAT'S INCLUDED
One (1) Juniper EX4300-48MP. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
Condition: Refurbished, Tested & Guaranteed EX4300-48MP was tested by Townsend Networks technicians before listing. The test process is on /testing-process.
WARRANTY & RETURNS
EX4300-48MP has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on /warranty and /legal/refunds.
QUESTIONS AND ANSWERS
What ports does the EX4300-48MP have? The EX4300-48MP has 48 × 1GbE (24 × 10GbE), with uplinks of 4x 40GbE QSFP+ and 52 data ports in all. Which way does the air flow on the EX4300-48MP? The airflow of the EX4300-48MP is front-to-back. What power does the EX4300-48MP use? The EX4300-48MP uses AC, a PoE budget of 1100 W and 802.3bt PoE++ (up to 95W/port). What are the size and weight of the EX4300-48MP? The EX4300-48MP measures Base unit 17.36 x 1.72 x 18.39 in (44.1 x 4.37 x 46.7 cm), W x H x D and weighs 13 lb (5.9 kg) no PSU/fans; 16.1 lb (7.3 kg) with one PSU and two fan modules. How much rack space does the EX4300-48MP take? The EX4300-48MP takes 1 U of rack space. What software does the EX4300-48MP run? The EX4300-48MP runs Junos OS.
