MX104-DC
MX104-DC Juniper Router, DC Power, Refurbished, 4x 10GbE SFP+
Refurbished, tested & guaranteedEn existencia
Condition: Refurbished, Tested & Guaranteed
MX104-DC, in stock, ships worldwide.
$3,995
¿Prefiere orden de compra o transferencia bancaria? También las aceptamos. Solo pídalo.
- Model
- MX104-DC
- Network Ports
- 4 × 10GbE
- Connectors
- SFP+
- Type
- Router
- Condition
- Refurbished, tested & guaranteed
Probado en nuestras instalaciones por técnicos certificados antes de enviarse. Términos de la garantía
The Juniper MX104-DC is a router from the Juniper MX104 family with 4 ports of 10GbE SFP+ and DC power. It runs Junos OS. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One unit per order.
Juniper MX104-DC / MX104 router chassis, 4 MIC slots (empty), 4x10GE SFP+ built-in ports, DC power supply, 3.5U
HOW IT DIFFERS
MX104-DC is the DC-powered MX104. Juniper's guide gives the DC supply three input choices, nominal 24, 48 or 60 VDC, each on a single DC input that needs its own circuit breaker, with 800 W of maximum output. Up to two supplies fit in slots PS 0 and PS 1, and the router cannot run on AC and DC together. Its sister MX104-AC takes AC supplies with the same 800 W output and a 10 A maximum per inlet at 100 VAC.
TECHNICAL DETAILS
Brand: Juniper Family: MX104 Management ports: ETHERNET port on the Routing Engine, RJ-45, 10/100/1000 Mbps Operating system: Junos OS Rack units: 3.5 rack units (U; that is, 6.125 in., or 15.55 cm) tall Airflow: intake on the right side of the chassis, exhaust out the left side Power input: DC Throughput: 80 Gbps system capacity Dimensions: 6.09 in. (15.47 cm) H x 17.22 in. (43.7 cm) W x 9.461 in. (24 cm) D Weight: 19.56 lb (9 kg), chassis without power supplies, fan tray, or MICs Mounting: 19-in. equipment racks, telco open-frame racks, or enclosed cabinets Fans: one hot-swappable fan tray that contains five fans Power supplies: up to two AC or DC power supplies Input voltage: 18 to 30 VDC (24 nominal); -39 to -56 VDC (48 nominal); -39 to -72 VDC (60 nominal) Power draw (typical): 625 W (DC router, with MICs) Operating temperature: Central office: 23° F (-5° C) to 131° F (55° C); harsh: -40° F (-40° C) to 149° F (65° C) Operating humidity: 5% to 85%, noncondensing Operating altitude: No performance degradation to 6,000 ft (1,900 m) CPU: 1.8-GHz CPU (Routing Engine) Memory (DRAM): 4-GB DDR3 RAM (mini DIMM) (Routing Engine) Flash storage: 8-GB on-board NAND Flash (Routing Engine) Console port: CONSOLE port on the Routing Engine, RJ-45 serial connector USB port: Two USB ports on the Routing Engine
MAKER'S DOCUMENT
https://www.juniper.net/documentation/us/en/hardware/mx104/mx104.pdf
WHAT'S INCLUDED
One (1) Juniper MX104-DC.
CONDITION & TESTING
Condition: Refurbished, Tested & Guaranteed MX104-DC was tested by Townsend Networks technicians before listing. The test process is on /testing-process.
WARRANTY & RETURNS
MX104-DC has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on /warranty and /legal/refunds.
QUESTIONS AND ANSWERS
What software does the MX104-DC run? The MX104-DC runs Junos OS.
¿Tiene consultas? Llame al 415-626-4231 o escriba a sales@townsendnetworks.com. Le responderá una persona real que conoce el hardware, no un centro de llamadas.
