ICX6450-48 Brocade Switch, Refurbished, 48x 1GbE RJ45, 2x 1GbE SFP+ and 2x 1/10GbE SFP+
- Condition
- Refurbished, tested & guaranteed
- WARRANTY & RETURNS
- ICX6450-48 has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
- Availability
- In stock
Orders placed by 12pm ship the same day.
A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.
The Brocade ICX6450-48 is a switch from the Brocade ICX6450 family with 48 ports of 1GbE RJ45, 2 ports of 1GbE SFP+ and 2 ports of 1/10GbE SFP+. It runs RUCKUS FastIron. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
- Model
- ICX6450-48
- Network Ports
- 50 × 1GbE
- Connectors
- RJ45, SFP+
- Type
- Switch
- Condition
- Refurbished, tested & guaranteed
Technical details
| Brand | Brocade |
|---|---|
| Family | ICX6450 |
| Uplinks | 2x 1/10GbE SFP+ |
| Total ports | 52 |
| Fastest port | 10GbE |
| Management ports | Out-of-band Ethernet management: 10/100/1000 Mbps RJ-45 |
| Operating system | RUCKUS FastIron |
| Airflow | Side-to-back |
| Dimensions | 1.7 in. (H) × 17.44 in. (W) × 14.57 in. (D); 4.34 cm (H) × 44.3 cm (W) × 37 cm (D) |
| Weight | 11.07 lb (5.02 kg) |
| Fans | Quiet fans at less than 40 dB |
| Power supplies | Integrated AC power supply for system and PoE power; internal rating 100 W |
| Input voltage | Universal 100 to 240 VAC |
| Heat output | 186 BTU/hr (no PoE load) |
| Operating temperature | 0°C to 45°C / 32°F to 113°F |
| Storage temperature | -40°C to 70°C / -40°F to 158°F |
| Operating humidity | 5% to 95%, non-condensing |
| Acoustic noise | 37.2 dBA (25°C) |
| MTBF | 756,081 hours (25°C, CL: 60%) |
| Switching capacity | 176 Gbps (data rate, full duplex) |
| Forwarding rate | 132 Mpps (data rate, full duplex) |
| MAC addresses | 16,000 |
| IPv4 routes | 12,000 (IPv4), in hardware |
| IPv6 routes | 2,140 (IPv6), in hardware |
| VLANs | 4,096 |
| Jumbo frames | 9,216 bytes |
| Console port | RJ-45 serial |
Brocade ICX6450-48 / 48-port 1GbE switch, 2x 1GbE SFP+ (upgradable to 10GbE) and 2x 1GbE/10GbE SFP+ uplink/stacking ports
WHAT'S INCLUDED
One (1) Brocade ICX6450-48. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
Condition: Refurbished, Tested & Guaranteed ICX6450-48 was tested by Townsend Networks technicians before listing. The test process is on the testing process.
