ICX6650-56-E-ADVBrocade
ICX6650-56-E-ADV Brocade Switch, AC Power, Refurbished, 56x 1/10GbE SFP+ and 6x 10/40GbE QSFP+
Switches
- Part number
- ICX6650-56-E-ADV
- Condition
- Refurbished, tested & guaranteed
- WARRANTY & RETURNS
- ICX6650-56-E-ADV has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
- Availability
- In stock
$3,955
Free US ground shippingOrders placed by 12pm ship the same day.
We photograph the actual unit on request before you commit. Request photos
Prefer a PO or wire? We take those too. Just ask.
Questions about the ICX6650-56-E-ADV? Call 415-626-4231 or email sales@townsendnetworks.com.
We photograph the actual unit on request before you commit. Request photos
Condition: Refurbished, Tested & Guaranteed
ICX6650-56-E-ADV, in stock, ships worldwide.
The Brocade ICX6650-56-E-ADV is a switch from the Brocade ICX6650 family with 56 ports of 1/10GbE SFP+, 6 ports of 10/40GbE QSFP+ and AC power. It is a Layer 3 managed platform that runs RUCKUS FastIron. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. One switch per order, with a rack-mount kit and the power cable(s) to match.
- Maker description
- Brocade ICX 6650 with 56 10 GbE SFP+ ports enabled. Includes two 250 W AC power supplies and two fan units, power-supply-side exhaust (port-side intake) airflow. Advanced software. No optics.
- HOW IT DIFFERS
- ICX6650-56-E-ADV is the Brocade ICX 6650 with all 56 of its front 10 GbE SFP+ ports enabled, two 250 W AC power supplies, power-supply-side exhaust airflow and advanced software. Its sister ICX6650-48-E-ADV is the same bundle with 48 ports enabled.
Specifications
- Model
- ICX6650-56-E-ADV
- Network Ports
- 56 × 1/10GbE
- Connectors
- SFP+, QSFP+
- Type
- Switch
- Condition
- Refurbished, tested & guaranteed
Technical details
| Brand | Brocade |
|---|---|
| Family | ICX6650 |
| Uplinks | 6x 10/40GbE QSFP+ |
| Total ports | 62 |
| Fastest port | 40GbE |
| Layer | Layer 3 (managed) |
| Operating system | RUCKUS FastIron |
| Rack units | 1U |
| Airflow | Power-supply-side exhaust (port-side intake) |
| Power input | AC |
| Dimensions | 1.732 x 16.88 x 16.00 in (44 x 429.0 x 406.4 mm) |
| Weight | 8.41 kg (18.5 lb) with two power supplies, two fans, without transceivers |
| Power supplies | Two 250 W AC power supplies |
| Input voltage | AC 100 to 240 VAC nominal; DC 40 to 60 VDC nominal |
| Power draw (maximum) | 230 W |
| Heat output | 478 BTU/hour |
| Operating temperature | -5°C to 55°C (23°F to 131°F) at sea level |
| Operating humidity | 5% to 95%, non-condensing |
| Operating altitude | Up to 9,842 ft (3,000 m) |
| Acoustic noise | 46.7 dB |
| Switching capacity | 1,600 Gbps line-speed full-duplex throughput |
| Forwarding rate | 1,190 Mpps |
| Packet buffer | 8 MB |
| Latency | 1,100 to 1,800 nanoseconds |
WHAT'S INCLUDED
One (1) Brocade ICX6650-56-E-ADV. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION & TESTING
- Condition: Refurbished, Tested & Guaranteed
- ICX6650-56-E-ADV was tested by Townsend Networks technicians before listing.
- The test process is on the testing process.
Ask about the ICX6650-56-E-ADV
