Is the Juniper MPC-3D-16XGE, MPC3E, MPC4E and MIC-3D-20GE line cards end of life?

Name: MPC4E-3D-32XGE-SFPP Juniper Line Card, Refurbished, 32x 10GbE SFP+
Brand: Juniper
SKU: MPC4E-3D-32XGE-SFPP
Price: 7065.00 USD
Availability: InStock

Juniper ended the sale of the Juniper MPC-3D-16XGE, MPC3E, MPC4E and MIC-3D-20GE line cards on June 30, 2021. Its support ended on June 30, 2026. The dates are from the maker notice linked in the end of sale table on this page. The hardware keeps working after them; what ends is the maker's side: new software fixes, support cases and replacement under a maker contract.

MPC4E-3D-32XGE-SFPP Juniper Line Card, Refurbished, 32x 10GbE SFP+

Condition: Refurbished, tested & guaranteed
WARRANTY & RETURNS: MPC4E-3D-32XGE-SFPP has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
Availability: In stock

$7,065

Free US ground shipping

Orders placed by 12pm ship the same day.

Request a quote 415-626-4231

A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.

The Juniper MPC4E-3D-32XGE-SFPP is a line card with 32 ports of 10GbE SFP+. It is a module that installs into a host chassis and does not run on its own. This unit is refurbished (used): inspected, powered on and functionally tested by Townsend Networks technicians before listing. It ships as the module only.

Compatible with: MX240, MX480, MX960, MX2010 and MX2020 routers with normal-capacity or high-capacity power supplies and fan trays; Junos OS 12.3R2 and later. Thirty-two fixed 10-Gigabit Ethernet ports.

Model: MPC4E-3D-32XGE-SFPP
Network Ports: 32 × 10GbE
Connectors: SFP+
Type: Line Card
Condition: Refurbished, tested & guaranteed

Technical details

Brand	Juniper
Layer	Layer 3 (managed)
Weight	19.4 lb (8.8 kg)
Power draw (maximum)	610 W (12.7 A at 48 V)
Switching capacity	Line-rate throughput of up to 260 Gbps
Jumbo frames	9,192 bytes for host-bound packets; 9,500 bytes from Junos OS 16.1R1

Juniper datasheet

Testing process

End of sale and support

Model	Announced	End of sale	End of support	Notice
Juniper MPC-3D-16XGE, MPC3E, MPC4E and MIC-3D-20GE line cards	2020-06-30	2021-06-30	2026-06-30	Juniper notice

Questions about the Juniper MX Line Cards family

Is the Juniper MPC-3D-16XGE, MPC3E, MPC4E and MIC-3D-20GE line cards end of life?: Juniper ended the sale of the Juniper MPC-3D-16XGE, MPC3E, MPC4E and MIC-3D-20GE line cards on June 30, 2021. Its support ended on June 30, 2026. The dates are from the maker notice linked in the end of sale table on this page. The hardware keeps working after them; what ends is the maker's side: new software fixes, support cases and replacement under a maker contract.

MPC4E with 32x10GE SFPP Ports L2/L2.5 Reduced L3

WHAT'S INCLUDED

One (1) Juniper MPC4E-3D-32XGE-SFPP. Ships as the module only; it installs into a host chassis, so no rack kit, power cables or console cord are included.

CONDITION & TESTING

Condition: Refurbished, Tested & Guaranteed MPC4E-3D-32XGE-SFPP was tested by Townsend Networks technicians before listing. The test process is on /testing-process.
