ICX8200-24FX Ruckus Switch, New, 16x 1/10GbE SFP+ and 8x 1/10/25GbE SFP28
- Condition
- New
- WARRANTY & RETURNS
- ICX8200-24FX has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
- Availability
- In stock
$3,955
Free US ground shippingOrders placed by 12pm ship the same day.
A firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.
The Ruckus ICX8200-24FX is a switch from the Ruckus ICX8200 family with 16 ports of 1/10GbE SFP+ and 8 ports of 1/10/25GbE SFP28. It runs RUCKUS FastIron. This unit is new: unused, in its original packaging. One switch per order, with a rack-mount kit and the power cable(s) to match.
- Model
- ICX8200-24FX
- Network Ports
- 16 × 1/10GbE
- Connectors
- SFP+, SFP28
- Type
- Switch
- Condition
- New
Technical details
| Brand | Ruckus |
|---|---|
| Family | ICX8200 |
| Uplinks | 8x 25GbE SFP28 |
| Total ports | 24 |
| Fastest port | 25GbE |
| Operating system | RUCKUS FastIron |
| Airflow | Reversible Airflow Option: No |
| Throughput | 720 Gbps switching capacity |
| Power supplies | Redundant Power Option: No; Hot Swap Internal Power Supplies & Fans: No |
| Input voltage | AC: 100 to 240 V AC at 50 to 60 Hz |
| Stacking | Yes; Switches per Stack, maximum 12; Aggregate Stack Bandwidth, maximum 1200 Gb/s |
| Certifications | ROHS: Compliant/Exempted; UK-ROHS: Compliant/Exempted |
What buyers ask
- What ports and capacity does the ICX 8200-24FX have?
- Ruckus lists the ICX 8200-24FX 10G fiber model with sixteen 1/10 GbE SFP+ ports and eight 1/10/25 GbE uplink and stacking SFP28 ports. Its comparison table gives it 720 Gbps of switching capacity and 533 Mpps of forwarding capacity, full duplex.
- How many ICX 8200 switches can be stacked, and over what distance?
- Ruckus gives the ICX 8200 up to 12 switches per stack, and says stacking comes standard with all ICX 8200 models. The stacking ports are the SFP28 uplink ports, and the maximum distance between stacked switches is 10 km.
- Does the ICX 8200-24FX have a redundant power supply?
- Ruckus describes the ICX 8200 fiber models, the 24F, 48F and 24FX, as offering a single integrated power supply, with one RJ-45 port for out-of-band network management, one USB Type-C console port, one RJ-45 serial console port and one USB port for external file storage.
- Does the ICX 8200-24FX need a licence for OSPF, BGP or the other advanced Layer 3 features?
- Ruckus lists base IPv4 and IPv6 Layer 3 routing, static routing and RIP, as included on every ICX 8200 model. The advanced IPv4 and IPv6 routing features OSPF, VRRP, VRF, GRE, PIM, PBR and BGP are listed as available with a licence.
16×1/10GbE SFP+ ports 8×25 GbE SFP28 stacking/uplink ports
WHAT'S INCLUDED
One (1) Ruckus ICX8200-24FX. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION
Condition: New A new, unused unit in its original packaging. Cosmetic handling marks on the outer box are possible for warehouse stock.
