ICX8200-24P Ruckus Switch, New Open Box, 24x 1GbE PoE+ RJ45 and 4x 1/10/25GbE SFP28
- Condition
- New, open box
- WARRANTY & RETURNS
- ICX8200-24P has a 3-year warranty and a 30-day return policy. DOA units are replaced or refunded. Full terms are on the warranty page and the refund policy.
- Availability
- In stock
$1,880
Free US ground shippingA firm price comes back, typically the same business day. Prefer a PO or wire? We take those too. Just ask.
The Ruckus ICX8200-24P is a switch from the Ruckus ICX8200 family with 24 ports of 1GbE PoE+ RJ45 and 4 ports of 1/10/25GbE SFP28. It runs RUCKUS FastIron. This unit is new, open box: unused, in its original packaging. One switch per order, with a rack-mount kit and the power cable(s) to match.
- Model
- ICX8200-24P
- Network Ports
- 24 × 1GbE
- Connectors
- RJ45, SFP28
- Type
- Switch
- Condition
- New, open box
Technical details
| Brand | Ruckus |
|---|---|
| Family | ICX8200 |
| Uplinks | 4x 1/10/25GbE SFP28 |
| Total ports | 28 |
| Fastest port | 25GbE |
| Management ports | RJ45 Ethernet port (For out of band network management): Yes |
| PoE | Yes |
| PoE standard | 802.3at PoE+ |
| PoE budget | 370 W |
| Operating system | RUCKUS FastIron |
| Airflow | Fanless Mode.*** Front and side to back |
| Throughput | 248 Gbps switching capacity, 184 Mpps forwarding |
| Dimensions | 4.40 cm (1.73 in) x 44.00 cm (17.32 in) x 28.00 cm (11.02 in) |
| Weight | 4.34 kg 9.57 lb |
| Power supplies | Power supply rated max (AC) 525 W; C14 power inlet |
| Input voltage | AC: 100 to 240 VAC @ 50 to 60 Hz |
| Operating temperature | 0°C to 45°C (32°F to 113°F) at sea level |
| Operating humidity | 10% to 90% at 50°C (122°F), non-condensing |
| Operating altitude | 0 to 3,048 m (10,000 ft) |
| Acoustic noise | 41.0 dBA (25°C, min fan speed) |
| MTBF | 1,550,360hr (25°C) |
| Memory (DRAM) | 4 GB |
| Flash storage | 8 GB NVRAM (eMMC) |
| MAC addresses | 32K (maximum) |
| IPv4 routes | 16k IPv4 (maximum routes in hardware) |
| IPv6 routes | 4k IPv6 (maximum routes in hardware) |
| VLANs | 4,095 (maximum) |
| Jumbo frames | 9,216 bytes (maximum jumbo frame size) |
| Packet buffer | 4 MB |
| Stacking | 12 switches per stack; 1200 Gb/s aggregate stack bandwidth (maximum) |
| Console port | USB Type-C port; RJ45 serial port |
| USB port | USB Type-A port (For external file storage) |
| Certifications | FCC Part 15 Subpart B (Class A); UL 62368-1; TAA compliant (all ICX 8200 SKUs) |
Questions and answers
- What ports does the ICX8200-24P have?
- The ICX8200-24P has 24 × 1GbE, with uplinks of 4x 1/10/25GbE SFP28 and 28 data ports in all.
- What power does the ICX8200-24P use?
- The ICX8200-24P uses a PoE budget of 370 W and 802.3at PoE+.
24x10/100/1000 Mbps PoE+ ports, 4x25 GbE SFP28
WHAT'S INCLUDED
One (1) Ruckus ICX8200-24P. Includes a rack-mount kit and the power cable(s) to match the switch.
CONDITION
Condition: New Open Box A new, unused unit in its original packaging. Cosmetic handling marks on the outer box are possible for warehouse stock.
